description
16 IP channelsVideo compression: Smart H.265+, H.265, Smart H.264+, H.264, MJPEGSimultaneous or heterogeneous HDMI (4K) and VGA (1080P) video output (configurable)Main display output division: 1, 4, 8, 9, 9, 16Secondary display output split: 1, 4, 8, 8, 9, 161 RCA audio input / 1 outputAudio compression: PCM, G.711a, G.711u, G726Recording resolution: 16MP, 12MP, 8MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, 960P, 720P, D1, CIFBandwidth with AI disabled: 256Mbps incoming, 256Mbps recording, 256Mbps outgoingAI enabled bandwidth: 180 Mbps inbound, 180 Mbps recording, 180 Mbps outboundAI disabled decoding capacity: 2 channels at 16MP (30 fps), 2 channels at 12MP (30 fps), 4 channels at 8MP (30 fps), 6 channels at 5MP (30 fps), 8 channels at 4MP (30 fps), 16 channels 1080P (30 fps)AI-enabled decoding capability: 1 channel at 16MP (30 fps), 2 channels at 12MP (30 fps), 3 channels at 8MP (30 fps), 4 channels at 5MP (30 fps), 6 channels at 4MP (30 fps), 12 channels 1080P (30 fps)Recording modes: general, motion detection, intelligence, alarmVideo sensor alarm, privacy mask alarm, video loss, scene change, PIR alarm, external cameraAI on recorder:
Perimeter protection up to 2 channels with 10 IVS rules per channel.Face detection with 1-channel attributes and up to 12 frames per second.Face recognition with 1-channel attributes, up to 12 images per second and up to 10 databases with 200,000 images.SMD Plus up to 4 channels with filtering between people and vehicles.AI support from compatible IP cameras:
Supports up to 8 IP cameras with perimeter protection.Supports up to 8 IP cameras with face detection.Supports up to 8 IP cameras with face recognition.Supports up to 8 IP cameras with SMD Plus.Supports up to 4 IP cameras with ANPR (up to 20,000 license plates with whitelist/blacklist).Up to 16 channel playback16 alarm inputs / 4 alarm outputsInternal capacity for 4 SATA HDD up to 16TB (sold separately)Gigabit RJ45 network port (10/100/1000Mbps)Network Protocols: HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, SNMP, UDP, SMTP, NTP, DHCP, DNS, IP Filtering, PPPoE, DDNS, FTP, Alarm Server, IP Search (supports Dahua IP cameras, DVRs, NVSs, etc.), P2P, Auto LoggingONVIF 22.06 (Profile T/S/G), CGI and SDK supportCompatible with web browsers, Android and iOS devicesServer Access: local network and InternetAbility to limit user access to cameras in local and/or remote modeCan be controlled remotely via Joystick keyboard connected via TCP/IPSending of eMails with photograph attached in alarmSending to FTP programmed or in alarmPossibility to send alarm, and be connected to video surveillance receiver softwarePossibility of fixed or dynamic IP through Dyndns, NoIP, DDNS Evolution, etc. service.Communication ports: 1 USB 2.0 port, 1 USB 3.0 port, 1 RS232 port, 1 RS485 port16 PoE ports (10/100Mbps, 802.3af/at)150W PoE deliveryPower supply: 100V ~ 240V AC, 50/60HzConsumption: ≤10W (excluding disks)Storage temperature from -20°C ~ +60°COperating temperature from -10°C ~ +55°CRelative humidity 10%~93%.Dimensions: 440 (W) x 76 (H) x 415.6 mmNet weight: 4.82 kgGross weight: 6.78 kgRack or desktop installation
