- Bandwidth:
AI Disabled: 384Mbps input, 384Mbps recording and 384Mbps output.
AI Enabled: 200Mbps input, 200Mbps recording and 200Mbps output.
- Decoding Capacity:
AI Disabled => 2CH-32MP@17IPS, 2CH-24MP@17IPS, 4CH-16MP@25IPS,
5CH-12MP@25IPS, 8CH-8MP@25IPS, 12CH-5MP@25IPS, 16CH-4MP@25IPS,
32CH-1080P@25IPS.
AI Enabled => 1CH-32MP@17IPS, 1CH-24MP@17IPS, 2CH-16MP@25IPS,
4CH-12MP@25IPS, 4CH-8MP@25IPS, 8CH-5MP@25IPS, 12CH-4MP@25IPS,
24CH-1080P@25IPS.
- ONVIF T/S/G Profiles, CGI, SDK.
- 4 Channel Perimeter Protection with 10 IVS rules per channel.
- 2 Channel Face Detection: Maximum 12 facial images per second on each channel.
- 2 Channel Face Recognition: Up to 20 facial databases with up to 200,00 facial images, with a total capacity of 2.5G. Maximum 12 facial images per second on each channel.
- 8 Channels SMD Plus: AI Search with object classification (People, Vehicles).
- AcuPick AI, Camera + Recorder: Max. 16ch, 1 combined event per channel.
- Supports RAID 0/1/5/6/10.
- Power Supply: 100V-240Vac (Max 13W (Without HDD). PoE Power (Max 25.5W@RJ45) up to 150W.
- Dimensions and Weight: 440.1x457.9x89.1mm / 6.90Kg (Without HDD).
- Supports N+M Cluster.
*WizSense Series: Perimeter Protection, Face Detection, Face Recognition, SMD Plus.
IMPORTANT NOTE: AI functions cannot be used simultaneously (SMD, facial recognition, perimeter protection...).
