AI disabled decoding capacity: 2 channels at 32MP (30 ips), 2 channels at 24MP (30 ips), 4 channels at 16MP (30 ips), 5 channels at 12MP (30 ips), 8 channels at 8MP (30 ips), 12 channels at 5MP (30 ips), 16 channels at 4MP (30 ips), 32 channels at 1080P (30 ips), 128 channels at D1 (30 ips)
AI-enabled decoding capability: 1 channel at 32MP (30 fps), 1 channel at 24MP (30 fps), 2 channels at 16MP (30 fps), 2 channels at 12MP (30 fps), 4 channels at 8MP (30 fps), 6 channels at 5MP (30 fps), 8 channels at 4MP (30 fps), 16 channels at 1080P (30 fps), 80 channels in D1 (30 fps)
General, motion detection, intelligent, alarm and POS recording modes
Video sensor alarm, masking alarm, video loss alarm, scene change alarm, PIR alarm, IP camera
Playback of up to 16 channels
32 alarm inputs / 16 alarm outputs
Internal capacity for 16 SATA III HDD up to 20TB (sold separately)
Supports RAID 0/1/5/6/10, disk pooling and hot-swappable replacement
1 eSATA port
IA port on the recorder:
Perimeter protection: 32 channels in simultaneous mode, 24 channels in heterogeneous mode, 10 IVS rules per channel.
Face detection: 8 channels in simultaneous mode, 5 channels in heterogeneous mode, up to 12 images per second and per channel
Face recognition: 32 channels in simultaneous mode, 16 channels in heterogeneous mode, up to 12 images per second and up to 40 databases with 300 000 images
SMD Plus: 32 channels with filtering between people and vehicles
Video metadata: 8 channels with attributes of people and vehicles
AI support from compatible cameras:
Supports up to 64 cameras with perimeter protection.
Supports up to 64 cameras with face detection
Support up to 64 cameras with face recognition
Support up to 64 cameras with SMD Plus
Supports up to 64 cameras with video metadata
Supports up to 64 ANPR cameras (up to 20,000 whitelists/blacklists)
Watermarking to preserve video integrity
4 RJ45 network ports (10/100/1000/2500Mbps)
Network protocols: HTTP, HTTPS, TCP/IP, IPv4, RTSP, UDP, NTP, DHCP, DNS, SMTP, UPnP, DDNS, Alarm Server, IP Search (Supports Dahua IP cameras, DVR, NVS, etc.), Multicast, P2P, Auto Logging, ISCSI
Compatible with ONVIF 22.06 (S/G/T), SDK, CGI
Compatible with Chrome, IE, Safari, Edge and Firefox browsers and iOS and Android devices
Server Access local network and Internet
Ability to limit user access to cameras in local and/or remote mode
Can be controlled remotely via Joystick keyboard connected by TCP/IP
Sending of eMails with photo attached in alarm
Sending to FTP programmed or in alarm
Possibility to send alarm, and be connected to video surveillance receiver software
Possibility of fixed or dynamic IP through Dyndns, NoIP, DDNS Evolution, etc. service.
Communication ports: 2 USB 3.0 ports, 2 USB 2.0 ports, 2 RS485 ports, 1 RS232 port
Power supply: 100V ~ 240V AC, 50/60Hz
Power consumption: ≤25W (excluding disks)
Storage temperature from -20°C ~ +60°C
Operating temperature from -10°C ~ +55°C
Relative humidity 10% ~ 93% (non-condensing)
Dimensions: 485 (W) x 133.2 (H) x 485 mm (3.5" x 485 mm)
